Hydraulic Garbage Truck Chassis

● JAC Junling H330 4×2
● Cab to Rear in 4.2m
● Size 5.995×2.19×3.1 m
● Light Duty Load 1.5 T
● Cummins 141ps Engine
● Ecological Class 4 Emission

Send Inquiry

FEAURES

● JAC Junling H330 4×2

● Cab to Rear in 4.2m

● Size 5.995×2.19×3.1 m

● Light Duty Load 1.5 T

● Cummins 141ps Engine

● Ecological Class 4 Emission

The truck chassis suitable for mounting following trucks as

● Tank Trucks with fuel water, refuel, chemical, food grade, gas , dry bulk etc.

● Fire Trucks with water ,foam, chemical, Compressed air and rescue type

● Garbage Trucks with rear loader, hook loader, skip loader, side loader

● Sewer Trucks with vacuum suction, combination sewer cleaner and jetter

● Sweeper Trucks with Waterless, Road Washing, Street sweeper

● Tow Trucks with flatbed, integrated, rotator style

● Asphalt Delivery Truck for Road Construction

● Bucket Trucks with Insulated, Articulated, Telescopic, Articulated Telescopic Type

● Truck Mounted with Crane of Articulating and Telescoping Type

● Van Trucks include Refrigerated, Mobile Workshop, Mobile Stage, Cage Box, Mobile LED and RV

GENERAL INFORMATION
Chassis Model	HFC5043XXYP91K6C2
Chassis Type	Special truck chassis
Drive Mode	4×2
Wheelbase	3308 mm
Cab to Rear	4.2 m
Engine	141 hp
Transmission	6+1 speed
Chassis length in	5.995 m
Chassis width in	2.19 m
Chassis height in	3.1 m
Front Track	1665mm
Rear Track	1525mm
Chassis Tare Weight	2.8 Ton
Recommended Loading	1.5 Ton
Gross Vehicle Weight	5 Ton
Max Driving Speed	95 KM/h
Manufacturing by	Hehui Factory
Loading Type	Light duty
Approach Angle Departure Angle	23 ° 14 °
Front Overhang Rear Overhang	1105 mm 1582 mm
ENGINE
Make	FOTON Cummins Co.,Ltd
Model	ISF3.8s5141
Series	FOTON Cummins 3.8
Cylinders	4 nos.
Fuel Type	Diesel
Cylinder Lineup	Vertical in line
Displacement	3.76 L
Ecological Class	5
Max Output in kw	105
Max Output in ps	141
Max Torque	440 N·m
Max Torque at rpm	1200-2200
Output at rpm	2600
Engine Type	Turbocharged, BOSCH common rail, high pressure direct injection, SCR
Cabin Width
Cab Model	H
Cab Type	Sleeper cab
Passengers Allowed	3 Nos
Seats and Sleeper Line	Seats Line: Front driver seat & Co-driver seat.
TRANSIMISSION,AXLE,SUSPENSION,CLUTCH
Make	LIUAN Transmission
Model	LC6T46
Type	Manual
Forward	6 Nos.
Reverse	1 Nos.
Casting Material	Steel
Front axle Model	2T
Front Axle Rating	1620 kg
Rear Axle Model	3T
Rear Axle Rating	2870 kg
Ratio	4.875
Leaf Spring	12/8+6
Steering	Standard
Clutch	Standard
TIRES, BRAKES,OIL TANKS
Tire Size	7.00R16LT 8PR
Tire Nos	6
Brakes	Air brake
Front Wheel Brake	Drum
Oil Tank Volume	100L Aluminum
ABS	Yes
Auto Window	No
GPS	No
